Turbo Charger GT1752S Upgrade 350hp for Ford Focus ST Ecoboost 2.0ltr 2013

POWERMAX™ DIRECT FIT PERFORMANCE TURBOCHARGER
2013 – 2018 Ford 2.0L EcoBoost Stage 1 Upgrade Supports Up To 350 BHP (260kW)
Focus ST | Escape / Kuga | Fusion | Taurus | MKC | MKT | MKZ

The Garrett PowerMax™ Stage 1 turbocharger upgrade for the 2013 – 2018 2.0L Ford EcoBoost engine platform is engineered to increase engine performance capability while maintaining OEM installation specifications. This direct drop-in turbocharger provides up to 16% more flow than OEM and will support up to 350 BHP* (260kW). Improvements in compressor efficiency and flow can be attributed to the 52mm fully-machined compressor wheel with advanced aero design. Inconel alloy turbine wheel and stainless steel turbine housings are rated for up to 950° C. This turbocharger kit comes fully assembled, calibrated, and is outline interchangeable with the OE hardware to ensure a perfect fit every time.

• Complete assembly with calibrated actuator
• 350hp @ Flyweel capability
• OE Level boost response
• GTX GENII Compressor wheel aero
• +16% Compressor flow over OE turbocharger
• Inco Turbine Wheel 950degC rated
• Stainless Steel turbine hosuing for durability and rated to 950degC
• Thrust bearing 360deg for boost support
• Speed Sensor port to run monitoring of compressor speeds fro durability

Brand: Garrett Motion
Type: GT1752S
Application:

• Ford Escape / Kuga - SE & Titanium 2014-2016
• Ford Focus ST 2013-2018
• Ford Fusion - SE & Titanium 2013-2016
• Ford Taurus - Limited, SE & SEL 2013-2017
• Ford MKC - Base, Black Label, Reserve, Premium & Select 2015-2017
• Ford MKT - Base & Black Label 2013-2016

Engine Manufacturer: Ford
Engine Model: EcoBoost 2.0L, 4 Cylinder
Fuel Type: Petrol
OEM Part Number: CJ5E-6K682-CA, CJ5E-6K682-CB, CJ5E-6K682-CC, CJ5E-6K682-CD, CJ5E-6K682-CE, CJ5E-6K682-CF, CJ5E-6K682-CG

Turbocharger Part Number: G886195-5001S

Fits OEM Versions: 53039700272, 53039880272, 53039700286, 53039880286, 53039700287, 53039880287, 53039700368, 53039880368, 53039700420, 53039880420, 53039700507, 53039880507

WARNING: The maximum allowable turbocharger speed is 214.9 krpm. The use of this product above 214.9krpm is at the owner’s risk, and can result in damage and premature failure. To protect the turbocharger from overspeed when operating, a speed sensor port is machined into the compressor housing for the fitment of speed sensor part numbers 781328-0001 (includes sensor and gauge), and 781328-0002 (includes speed sensor). Speed sensors sold separately.

*Performance results of this product are highly dependent upon your vehicle’s modifications and tuning/calibration. The target power has been calculated based strictly on choke flow of the compressor map (total turbo capability), which represents the potential flywheel power.
